SSIS 2012: Programmatically Create Catalog

I have a client that has already started migrating existing SQL Server environments to SQL Server 2012. Thus, this article will demonstrate creating a catalog and catalog folder using a Script Task component.

We begin by launching Microsoft Visual Studio and creating a new Integration Services Project which is located under Business Intelligence Projects category.
After you have assigned a project name, proceed to click and drag the Script Task into the Control Flow pane from the toolbox.
Right-click the script task and click on “Edit”
Under the Script Task Editor change the “ScriptLanguage” to “Microsoft Visual C# 2010”.
In Project Explorer, ensure the following references are added:
Back to the code window, ensure that the following namespaces are declared:
using System;
using Microsoft.SqlServer.Management.IntegrationServices;
using Microsoft.SqlServer.Management.Smo;
After the above declarations, proceed to create an instance of SMO Server to server “SQL12-PC”
Server SMO_DisHBI = new Server(“SQL12-PC”);
Create an instance of MOM – Managed Object Model class
Initialize MOM with SMO Server
IntegrationServices Is_DisHBI = new IntegrationServices(SMO_DisHBI);
//Create a catalog and assign a password.
//Ensure that the catalog name is “SSISDB” as per SQL Server 2012 RTM guidelines
Catalog sS_Vct = new Catalog(sS_Is, “SSISDB”, “password”);

//Create a catalog folder and assign a description
CatalogFolder sS_Vctf = new CatalogFolder(sS_Vct, “selectSifiso”, “Description of selectSifiso folder created via Script Task.”);

It’s that simple!



October 13, 2022
Sifiso is Data Architect and Technical Lead at SELECT SIFISO – a technology consulting firm focusing on cloud migrations, data ingestion, DevOps, reporting and analytics. Sifiso has over 15 years of across private and public business sectors, helping businesses implement Microsoft, AWS and open-source technology solutions. He is the member of the Johannesburg SQL User Group and also hold a Master’s Degree in MCom IT Management from the University of Johannesburg.
